| Model | HBFL-1422 | HBFL-1652 | HBFL-1880 | HBFL-2000 | HBFL-2400 |
| Netting Width | 1422mm | 1652mm | 1880mm | 2000mm | 2400mm |
| Motor | 5.5kw | 7.5Kw | 7.5kw | 7.5kw | 11kw |
| Efficiency | ≤45row/min | ≤45row/min | ≤45row/min | ≤45row/min | ≤45row/min |
| Twine diameter | 1.9-2.5(mm) | 1.9-2.5(mm) | 1.9-2.5(mm) | 1.9-2.5(mm) | 1.9-2.5(mm) |
| Side wire diameter | 2.0-3.5(mm) | 2.0-3.5(mm) | 2.0-3.5(mm) | 2.0-3.5(mm) | 2.0-3.5(mm) |
| Weight | 3.5T | 3.6T | 3.8T | 4.0T | 4.5T |
| Warp number | 11 | 12 | 13 | 18 | 23 |
| Dimension | 2.8*3.2*2.4(m) | 3.0*3.2*2.4(m) | 3.3*3.2*2.4(m) | 3.4*3.2*2.4(m) | 3.9*3.4*2.4(m) |
| Productivity | 21600 row/day (150m/h) | ||||
